5KW 48V MPPT Charge Controller Pure Sine Wave Hybrid Inverter

Hybrid Inverter - Single Phase 3K/5K

Product Overview:
Our Hybrid Inverter is designed to deliver reliable and efficient power for both residential and off-grid applications. With advanced features and robust performance, it is the ideal choice for those seeking a versatile and scalable energy solution.

Key Features:

1. Wide Battery Compatibility:
   The inverter is compatible with most common low-voltage batteries, including lead-acid and lithium batteries, offering flexibility for various energy storage needs.

2. High Power Output:
   The 3K model delivers a nominal power of 3000W, while the 5K model offers 5000W, making it suitable for a wide range of applications. The 5K model also supports parallel operation of up to 9 units, allowing for scalable power solutions.

3. Efficient Energy Conversion:
   With a peak efficiency of 93%, the inverter ensures minimal energy loss, maximizing the power output from your solar panels and batteries.

4. User-Friendly Interface:
   Equipped with an LCD screen, the inverter provides a safe and intuitive way for users to interact with the system. Additionally, remote monitoring is available via a mobile app, making it easy to manage your energy system from anywhere.

5. Intelligent Cooling System:
   The inverter features an intelligent fan cooling design, ensuring optimal performance even under high load conditions.

6. Comprehensive Protection:
   The inverter includes multiple protection features such as PV over voltage and current protection, battery over voltage and current protection, and output over current, short circuit, and over voltage protection. These features ensure the safety and longevity of your system.

Technical Specifications:

• Battery Input:

  • Battery Type: U-100V/Ux64-Src4

  • Battery Voltage: 24VAC (3K model), 48VAC (5K model)

• PV Input:

  • Max PV Array Power: 4000W (3K model), 6000W (5K model)

  • MPPT Range Operating Voltage: 60V-115V

  • Max Solar Charge Current: 80A

• AC Output:

  • Max AC Charge Current: 120A

  • Voltage Range: 170-260VAC (for computers), 90-280VAC (for home appliances)

  • Frequency Range: 50/60 Hz

• General:

  • Communication: USB/Wi-Fi (GPRS, RS485/CAN, Dry-contact)

  • System Protection Rating: IP54

  • Dimensions: 300450110.5 mm

  • Weight: 12.5 kg (3K model), 13 kg (5K model)

  • Operating Temperature: -25°C to 60°C

  • Storage Temperature: -40°C to 70°C

Why Choose Our Hybrid Inverter?

• Versatility: Compatible with a wide range of batteries and scalable for future expansion.

• Efficiency: High conversion efficiency ensures maximum power output.

• Ease of Use: Intuitive interface and remote monitoring capabilities.

• Reliability: Robust protection features ensure safe and long-lasting operation.

Applications:

• Residential solar power systems

• Off-grid and hybrid energy systems

• Backup power solutions

Experience the future of energy management with our Hybrid Inverter – reliable, efficient, and smart.
