RA Series Bidirectional Inverter – Efficient Energy Conversion, Intelligent Power Management
Product Overview
The RA Series Bidirectional Inverter is a high-performance power conversion device integrating both charging and inverter functions, compatible with lead-acid, LiFePO₄, and NCM batteries. It supports bidirectional conversion between AC 220V/110V and DC 12V/24V, with a maximum charging current of 100A and an inverter output power of 2KW–3KW, making it ideal for home backup, commercial use, and outdoor applications.
Key Features
-
High Efficiency & Energy Saving
-
≥91% charging efficiency and 92% inverter efficiency, minimizing energy loss.
-
Low no-load consumption (≤20W), reducing standby power waste.
-
Advanced Protection & Safety
-
Multiple safeguards: Over-voltage, under-voltage, over-current, short-circuit, and over-temperature protection.
-
Smart thermal control: Reduces output at 95°C, shuts down at 105°C, and resumes at 85°C for extended durability.
-
Flexible & Adaptive
-
Simultaneous charge & discharge (1400W charging + 1800W bypass) for high-demand scenarios.
-
Wide input range (AC 180–264V / DC 10.5–16V), ensuring stable operation in fluctuating power conditions.
-
User-Friendly Operation
-
5-button control panel with 17 customizable settings (battery type, charging voltage, output frequency, etc.).
-
LCD display for real-time monitoring of power, frequency, battery status, and fault codes.
Applications
-
Home Backup Power: Seamless switch to battery mode during outages.
-
Outdoor & RV Use: Reliable power for camping, road trips, and mobile setups.
-
Commercial Backup: Ensures uninterrupted operation for critical equipment.
Technical Specifications
-
Models: RA2000W (4000W peak), RA3000W (6000W peak)
-
THD: ≤3% (resistive load), pure sine wave output.
-
Operating Conditions: -10°C to +45°C, altitude <3000m.
-
Size/Weight: 241×345×121mm, 6.1KG (compact & portable).
Safety Notes
Choose RA Series – Smarter, More Reliable Power Conversion!
Learn More: Visit our website or contact customer service for details.
Electrical specifications |
| Model |
|
| Applicable Battery Type | Lead acid/LiFePO4/NCM battery |
| Charging Method | Constant current/constant voltage (CC/CV) |
| Cooling Method | Air Cooling |
| |
| Input | Voltage Range | 180~264VAC |
| Frequency Range | 47-63HZ |
| Maximum Effciency | ≥91% @220VAC |
| Maximum Current | 15Amax |
| PF value | ≥0.95 |
| Surge Current | ＜60ACold Start |
| Output | Rated Voltage | 13.2V (maximum charging voltage14.8V) |
| Rated Current | 100A |
| Maximum Power | 1400W |
| Voltage Accuracy | ±0.8V |
| Current Accuracy | ≤8% |
| Load Regulation | ≤5% |
| Dynamic Load Regulation | ≤5% |
| Battery Charging Voltage | 10.5V-14.5V |
| |
| Input | Voltage Range | 10.5~16V DC |
| Maxmum Effciency | 92% |
| Maximum Current | 180A 12.5V/280A 12.5VDC |
| Output | Rated Voltage | 220Vac @≥12.5 VDC |
| Rated Current | 13.64A @≥12.5VDC |
| Output Frequency | 50Hz/60Hz |
| Maximum Power | 2 000W (peak power4000W) @≥12VDC |
| 3000W (peak power6000W) @≥12VDC |
| Power Factor | ≥0.95 |
| THD | ≤3% (resistive load) |
| Bypass Power | 1800W.MAX(NA) |
| Charge And Discharge At The Same Time | Charge1400W+Bypass1800W(NA) |
| Bypass Inverter Switching Time | ≤30 ms (NA) |
| Others | Shell Material | Iron |
| Reference Weight | 6.1KG |
| Color | / |
| Reference Size | 241 * 345 * 121 mm |
| Reference Packaging | / |
|
|
|
