4KW 48V AC to Dc 110V 220V 5KVA Off Gird Pure Sine Wave Hybrid Solar Inverter

    Buy cheap 4KW 48V AC to Dc 110V 220V 5KVA Off Gird Pure Sine Wave Hybrid Solar Inverter from wholesalers

    Buy cheap 4KW 48V AC to Dc 110V 220V 5KVA Off Gird Pure Sine Wave Hybrid Solar Inverter from wholesalers
    • Buy cheap 4KW 48V AC to Dc 110V 220V 5KVA Off Gird Pure Sine Wave Hybrid Solar Inverter from wholesalers

    4KW 48V AC to Dc 110V 220V 5KVA Off Gird Pure Sine Wave Hybrid Solar Inverter

    Ask Lasest Price
    Brand Name : SZSSTH
    Model Number : SUF5000S4A1
    Certification : CE Rhos BSI
    Price : $213.1-231.6/pieces
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram
    Supply Ability : 100000pcs/month
    Delivery Time : 7 Work Days
    • Product Details
    • Company Profile

    4KW 48V AC to Dc 110V 220V 5KVA Off Gird Pure Sine Wave Hybrid Solar Inverter

    Power Your World with UD Series Solar Inverters – Reliable, Efficient, and Smart Energy Solutions

    Uninterrupted Power, Pure Sine Wave Performance

    The UD Series Solar Inverters (800W–10,000W) deliver clean, stable, and efficient power for residential, commercial, and industrial applications. With pure sine wave output, these inverters ensure compatibility with sensitive electronics, providing seamless energy transition from grid to battery and solar.

    Key Features

    • High Efficiency MPPT Controller – Maximizes solar energy harvest with 98% efficiency.

    • Flexible Battery Support – Compatible with lead-acid, gel, water, and lithium batteries, offering versatile energy storage options.

    • Smart Charging & Protection – Adjustable charging current, battery anti-reverse protection, and overload/short-circuit safeguards.

    • WIFI/GPRS Connectivity – Monitor and control your system remotely for optimized performance.

    • Automatic Generator Start – Optional feature to auto-start generators during low battery conditions.

    • Wide Input Range – Supports 154–264VAC (standard) and 110V models (77–132VAC), adaptable to varying grid conditions.

    • DC Start & Self-Diagnosis – Ensures reliable operation with automatic fault detection.

    Technical Excellence

    • Output Power: 800W to 10,000W (scalable for diverse needs).

    • Battery Voltage: 12V/24V/48V options with optimized charging (e.g., 54.8VDC for 48V systems).

    • Solar Integration: Up to 6,400W PV array support (MPPT/PWM) with wide voltage ranges.

    • Robust Design: Operates in 0°C–40°C, storage at -15°C–45°C, and noise levels <45dB.

    Ideal For

    • Off-grid solar systems

    • Backup power solutions

    • Hybrid energy setups

    Choose UD Series – Where Innovation Meets Uninterrupted Power.

    model
    UDI012AP
    UDI512AP
    UD1524AP
    UD2024AP
    UD3024AM
    UO5048AM
    UD6348AM
    U012548AM
    UD10048AM
    Ac input voltage
    220VAC(standard)
    220VAC(standard)
    Input voltage range
    154-264VAC+3V(Nor Model)185-264VAC+3V(UPs model)
    110V机型:77-132VAC+3V(Nor Model)92-132VAC±3V(UPs model)
    Input frequency
    50/60Hz±5%
    50/60Hz±5%
    Output power
    1000VA
    800W
    1500VA
    1200W
    1500VA
    1200W
    2000VA
    1600W
    3000VA
    2400W
    5000VA
    4000W
    6300VA
    5000W
    10000VA
    8000W
    12500VA
    10000W
    AC model output Voltage
    The output voltage under the mains is thesame as the input voltage
    Battery model output voltage
    220VAC+10%(Custom110VAC+10%)
    Battery model output frequency
    50HZ or 60HZ±1%
    Battery model output wave
    Pure sine wave
    Battery type
    External lead-acid battery,Gel battery,water battery or Lithium battery
    Battery voltage
    12VDC
    12VDC
    24VDC
    24VDC
    24VDC
    48VDC
    48VDC
    48VDC
    48VDC
    Battery charging voltage
    13.7VDC
    13.7VDC
    27.4VDC
    27.4VDC
    27.4VDC
    54.8VDC
    54.8VDC
    54.8VDC
    54.8VDC
    Maximum PV array power
    12V:800W
    24V:1600W
    48V:3200W
    48V:6400W
    Solar input voltage range
    12V:PWM 15V-50VDC
    24V:PWM 30V-105VDC
    24V:MPPT 30V-150VDC
    48V:MPPT 60V-150VDC
    Maximum PV Display
    Open Circuit Voltage
    12V: PWM 50VDC
    24V: PWM 105VDC
    24V:MPPT 150VDC
    48V:MPPT 150VDC
    Maximum solar charging current
    60A
    120A
    Maximum AC Charge Current
    27A
    40A
    20A
    30A
    60A
    40A
    50A
    80A
    100A
    load peak ratio
    (MAX)3:1
    Protective function
    Under themains:input overcurrent fuse
    Under inverter: overload protection,short circuit protection, low voltage protection
    (with battery anti-reverse connection, board).
    Status Display
    You can view parameters such as Ac voltage, Ac frequency, PVvoltage, Pv current, output voltage
    output frequency, battery voltage, load current and other parameters by turning the page keys.
    Voice prompt
    Low batteryprotection ouzzerlona peep
    Low batterybuzzer beeps every second
    Machine fault buzzer beeps
    Overload buzzer beeps
    When the overload is less than 130%, the buzzer will sound every second,and
    the output will be turned off after 30s. When the overload is greater than150%.the output will be turned off after 300ms.
    Operating temperature
    0°C~40℃
    Storage temperature
    -15°C~45°C
    Relative temperature
    -10°C~90℃C no condensation
    Noise
    <45dB
    size(L*W*H)mm
    465*310*135MM
    545*400*200MM
