    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology

    Ask Lasest Price
    Brand Name : SZSSTH
    Model Number : SSTH-MN1220
    Price : CN¥204.83/pieces 2-99 pieces
    • Product Details
    • Company Profile

    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology

    Max PV Voltage 48V 12V 24V 20A 250W Solar Panel Charge Controller with Advanced MPPT Technology

    Product Description
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    Good Guality Solar Panel Charge Controller Mppt 12V 24V 20A 250W MPPT Solar Charger Controller
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    Specification
    Parameters/Model
    MN10
    MN20
    MN30
    MN40
    Maximum Power Current
    12A
    20A
    30A
    40A
    Installation Lin mm2
    4mm2
    8mm2
    10mm2
    12mm2
    Installation Line(AWG)
    10 (AWG)
    8(AWG)
    7(AWG)
    6(AWG)
    Weight
    280g
    300g
    475g
    480g
    Dimensions
    143×89×46 mm
    187*97*61 mm
    System load loss
    ≤13mA
    Loop Buck
    ≤100mV
    Battery float voltage
    13.8V 12V system /27.6V 24V system
    Battery under voltage) protection
    10.6V 12V system /21.2V 24V system
    Battery (under voltage) recovery voltage
    12.6V 12V system /25.2V 24V system
    Charge mode
    MPPT MODE
    Operating Temperature
    -10~60°C
    Storage Temperature
    -30~70°C
    Humidity requirements
    ≤90%, No condensation
    Temperature compensation
    -4mV/Cell/°C
    Temperature Probe (built components)
    TC 100K thermistats
    aximum open circuit voltage of the solar panel
    18V-24V 12V system 36V-48V 24V system)
    Solar panels maximum open circuit voltage (V)
    ≤48V
    (Cases) 12V system standard configuration
    The peak voltage of the solar cell panel
    18V-25V
    18V-25V
    18V-25V
    18V-25V
    Peak power of solar cell panel
    50W-130W
    100W-260W
    200W-380W
    ≤500W
    Packing & Delivery
    48V 12V 24V 20A 250 Watt Solar Panel Charge Controller With Advanced MPPT Technology
    Package: natural box 1pc/Inner box;50pcs/CTN
